Cutting-Edge Camera Technology in Rice Color Sorters
Madhu Milling' rice color sorter machines are equipped with advanced optical and digital innovations, ensuring precision, efficiency, and ease of use. Here’s a look at the breakthrough features that set our machines apart:
1. Trichromatic 16,200-Pixel High-Speed Cameras
- Ultra-High Resolution: Captures fine details using trichromatic sensors.
- Double Scanning System: Recognizes defects as small as 0.04 mm², ensuring unmatched sorting accuracy.
- Superior Speed: Designed for high-throughput operations without compromising precision.
2. Smart Connectivity and Cloud Integration
- Smartphone Pairing: Operate and monitor the machine remotely via a dedicated app.
- Cloud Data Storage: Save up to 40 user profiles, making operations consistent across shifts or locations.
- Remote Diagnostics: Enables quicker service and system updates.
3. User-Friendly Interface
- 12″ Japanese Touch Screen: Intuitive and responsive, even in industrial environments.
- Windows-Based Operating System: Supports seamless software updates and smooth operation.
4. Advanced Image Processing
- Real-Time Defect Detection: Processes images at high speed to identify minute imperfections—tiny spots, faint lines, subtle yellows, etc.
- Precision Sorting Algorithms: Ensures only high-quality grains pass through.
5. Intelligent Dust Cleaning System
- Self-Triggered Mechanism: Automatically activates based on internal conditions.
- Maintains Optimal Visibility: Reduces dust accumulation inside the machine for uninterrupted performance.
6. Adaptive Illumination System
- Advanced Dimmable LED Lights: Adjusts intensity based on material and ambient light.
- Consistent Imaging Quality: Ensures clear, accurate detection regardless of grain type or environmental changes.
| Model | Channels | Sorting Resorting Combo | Capacity(t/hr) | Sorting Accuracy(%) | Rejection Ratio | Dimensions (L * B * H) in mm |
Air Compressor Suggested |
|---|---|---|---|---|---|---|---|
| RS-1004 | 256 | 2:1:1 | 2.5-3.0 | ≥99.99 | 1:55 | 2033x1610x1887 | 20 HP 90CFM |
| RS-1005 | 320 | 3:1:1/4:1 | 3.0-3.5 | ≥99.99 | 1:55 | 2348x1610x1887 | 25HP 110CFM |
| RS-1007 | 448 | 4:2:1 | 4.5-5.5 | ≥99.99 | 1:55 | 2978x1610x1887 | 30HP 129CFM |
| RS-1008 | 512 | 5:2:1 | 5.0-5.5 | ≥99.99 | 1:55 | 3293x1610x1887 | 40HP 150CFM |
| RS-1010 | 640 | 6:3:1 | 5.5-6.5 | ≥99.99 | 1:55 | 3933x1610x1887 | 50HP 230CFM |
